KSD301C 3/4”Thermortat Series
KSD301C 3/4” Thermostat Series
Technical Parameters
● Available with both open on Rise and Close on Rise type.
● Temperature Range:
a, ceramic: -30℃∽+270℃
b, bakelite: (automatic) -30℃∽+150℃ ; (manual) 30℃∽+150℃
● Tolerance:
(automatic) Min±3℃ Standard±5℃
(manual) Min±4℃ Standard±5℃
● A variety of mounting flanges are available to meet the request of installing.
Application:
● Air conditions, heating and ventilating equipment, vending machines, dryers, unit heaters, tabletop appliances, etc.
Approval:
● UL CQC TU V VDE CUL
